<B>Chipset: </B> AMD B550

<B>Rozmerový formát: </B> mATX Form Factor (244 mm x 244 mm) <B>Podpora pre procesory: </B> AMD AM4 Socket 3. Gen AMD Ryzen™ Processors <B>Pätica procesora: </B> AM4

<B>Pozícia na pamäti: </B> 4x DDR4 DIMM <B>Podpora pre pamäte: </B> *3rd Gen AMD Ryzén™ Processors - 4600( OC)/4400(OC)/4266(OC)/4133( OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory * Next Generation AMD Ryzen PRO Processors - 4800(OC)/4600(OC)/4466(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC) )/3600(OC)/3466(OC)/3333(OC)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory <B> Max. veľkosť operačnej pamäte: </B> 128 GB <B >Podpora pre pamäte typu: </B> DDR4 *Dual Channel Memory Architecture *ECC Memory (ECC mode) support varies by CPU

<B>Grafické výstupy: </B> (na základe procesora) *1x D-Sub *1x DVI-D *1x HDMI 2.1(4K@60HZ)

<B>Zvuková karta: </B> *Realtek ALC887 7.1 Surround Sound High Definition Audio CODEC

<B>Sieťová karta: </B> *Realtek RTL8111H 1Gb Ethernet

<B>Rozširujúce sloty: </B> *1x PCIe 4.0 x16 (x16 mode) *2x PCIe 3.0 x1

<B>RAID radič: </B> 0, 1, 10

<B>SATA: </B> *4x SATA 6Gb/s ports

<B> M.2 : </B> *1x M.2 Socket 3, s M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 a SATA modes) storage devices support *1x M.2 Socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 a SATA modes) storage devices support

<B>USB: </B> *<B>zadné USB porty ( celkom 6 )</B> *2x USB 3.2 Gen 2 port(s)(2 x Type-A) *4x USB 3.2 Gen 1 port(s )(4 x Type-A) *<B>predné USB porty ( celkom 6 )</B> *2x USB 3.2 Gen 1 port(s)(2 x Type-A) *4x USB 2.0 port(s)(4 x Type-A)

<B>Interné porty: </B> *1x CPU Fan connector(s) *2x Chassis Fan connector(s) *1x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) *2x USB 2.0 konektor(s) support(s) additional 4 USB 2.0 port(s) *1x M.2 Socket 3 s kľúčom M, typ 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode) *1x M.2 Socket 3 s kľúčom M, typ 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) *1x SPI TPM header *4x SATA 6Gb/s connector(s) * 1x S/PDIF out header(s) *1x 24-pin EATX Power connector(s) *1x 8-pin EATX 12V Power connectors *1x Front panel audio connector(s) (AAFP) *1x Clear CMOS jumper(s) * 1x System panel connector *1x COM port header *1x Speaker connector

<B>Externé porty: </B> *1x PS/2 klávesnica/mouse combo port(s) *1x DVI-D *1x D-Sub *1x HDMI *1x LAN (RJ45) port(s) *2x USB 3.2 Gen 2 (teal blue) (2 x Type-A) * 4x USB 3.2 Gen 1 (blue) Type-A * 3x Audio jack(s)

<B>Obsah balenia: </B> *User's manual *I/O Shield *2x SATA 6Gb/s cable(s) *1x Supporting DVD *1x M.2 SSD screw package(s)

<B>BIOS: </B>256 Mb Flash ROM, UEFI AMI BIOS

<B>Stránka výrobcu: </B> https://www.asus.com/Motherboards/PRIME-B550M-Khttps://www.asus.com/microsite/motherboard/ASUS-motherboards-Win11-ready/ https ://www.asus.com/support/FAQ/1046215
