X1228H, DLP 3D, XGA (1024x768), 4500ANSI, 20000:1, VGA, HDMI, 1x3W, 2.8 kg, ColorBoost 3D, ColorSafe II, LumiSense, životnosť lampy 6000 h


Model názov X1228H

Projection system DLP®

Resolution XGA (1,024 x 768) Maximum WUXGA (1,920 x 1,200)

Brightness 4,500 ANSI Lumens (Standard), 3,600 ANSI Lumens (ECO) (Compliant with ISO 21118 štandard)

Aspect ratio 4:3 (Native), 16:9 (Supported)

Contrast ratio 20,000:1

Throw ratio 1.94 ~ 2.16 (51"@2m)

Zoom ratio 1.1X

Projection lens F= 2.41~2.53, f = 21.85~24.01mm

Manual Zoom & Focus

Lamp life 6,000 Hours (Standard), 7,000 Hours (ECO), 10,000 Hours (ExtremeEco)

Noise level 32 dBA (Standard), 24 dBA (ECO)

Input interface
Analóg RGB/Component Video (D-sub) x 1
HDMI (Video, Audio, HDCP) x 1
PC Audio (Stereo mini jack) x 1
Composite Video (RCA) x 1

Output interface
PC Audio (Stereo mini jack) x 1
DC Out (5V/1A, USB Type A) x 1
Analóg RGB (D-sub) x 1

Control interface
RS232 (D-sub) x 1
USB (Type A) x 1, share output port

Dimensions 313 x 240 x 113.7mm (12.3" x 9.4" x 4.5")

Weight 2.8 Kg (6.17 lbs)
