Chipset: AMD B450

Rozmerový formát: mATX Form Factor (226 mm x 221 mm)
Podpora pre procesory: 3rd/2nd/1st Gen AMD Ryzén™/2nd a 1st Gen AMD Ryzén™ s Radeon™ Vega Graphics/Athlon™ s Radeon™ Vega Graphics Processors
Pätica procesora: AM4

Pozícia na pamäti: 2x DDR4 DIMM
Podpora pre pamäte: 4400( OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3300(OC)/3200(OC)/3000 (OC)/2933(OC)/2800(OC)/2666/2400/2133 MHz Un-buffered Memory
Max.veľkosť operačnej pamäte: 64 GB
Podpora pre pamäte typu: DDR4
•Dual Channel Memory Architecture
•ECC Memory (ECC mode) support varies by CPU

Grafická karta:
•Integrated Graphics Processor (na základe procesorov 2. a 1. generácie AMD s Radeon Grpahics/Athlon)

Zvuková karta:
• Realtek 7.1-Channel High Definition Audio CODEC

Sieťová karta:
• Realtek® RTL8111H

Rozširujúce sloty:
•3rd/2nd/1st Gen AMD Ryzen™ Processors
•1x PCIe 3.0 x16 (x16 mode)
•2nd a 1st Gen AMD Ryzen™ s Radeon™ Vega Graphics Processors
•1x PCIe 3.0 x16 (x8 mode)
• AMD Athlon™ s Radeónom™ Vega Graphics Processors
•1x PCIe 3.0 x16 (x4 mode)
•AMD B450 chipset
•2x PCIe 2.0 x1

RAID radič: 0, 1, 10

SATA:
•4x SATA 6Gb/s ports

M.2 :
•1x M.2 Socket 3 s kľúčom M, typ 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)

USB:
•zadné USB porty (celkom 6)
•4x USB 3.2 Gen 1 port(s)(4 x Type-A)
• 2x USB 2.0 port(s)(2 x Type-A)
•predné USB porty ( celkom 6 )
•2x USB 3.2 Gen 1 port(s)
•4x USB 2.0 port(s)

Interné porty:
•1x CPU Fan connector(s) (1 x 4 -pin)
•1x Chassis Fan connector(s) (1 x 4 -pin)
•1x USB 3.2 Gen 1(up to 5 Gbps) konektor(s) support(s) additional 2 USB 3.2 Gen 1 port(s) (19-pin)
•2x USB 2.0 konektor(s) support(s) additional 4 USB 2.0 port(s)
•1x M.2 Socket 3 s kľúčom M, typ 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
•1x SPI TPM header
•1x COM port(s) connector(s)
•4x SATA 6Gb/s connector(s)
•1x S/PDIF out header(s)
•1x 24-pin EATX Power connector(s)
•1x 8-pin ATX 12V Power connector(s)
•1x Front panel audio konektor(s) (AAFP)
•1x System panel(s)
•1x Clear CMOS jumper(s)
•1x COM port header
•1x Speaker connector

Externé porty:
•1x PS/2 klávesnica/mouse combo port(s)
•1x DVI-D
•1x D-Sub
•1x HDMI
•1x LAN (RJ45) port(s)
•4x USB 3.2 Gen 1 (blue) Type-A
•2x USB 2.0
•3x Audio jack(s)
•1x BIOS FlashBack™ Button(s)

Obsah balenia:
•User's manual
•I/O Shield
•2x SATA 6Gb/s cable(s)
•1x M.2 Anchor
•1x Supporting DVD

BIOS: 256 Mb Flash ROM, UEFI AMI BIOS
