Chipset: AMD B550

Rozmerový formát: ATX Form Factor (305 mm x 244 mm) Podpora pre procesory: AMD AM4 Socket 3. Gen AMD Ryzen™ Processors

Pozícia na pamäti: 4x DDR4 DIMM Podpora pre pamäte: *3rd Gen AMD Ryzen™ Processors - 4600( OC)/4400(OC)/4133(OC)/4000(OC)/3866(OC)/3600(OC)/3466 (OC)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory *Next Generation AMD Ryzeň PRO Processors - 5100( OC)/5000(OC)/4800(OC)/4600(OC)/4400( OC)/4133(OC)/4000(OC)/3866(OC)/3600(OC)/3466(OC)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory Max.veľkosť operačnej pamäte: 128 GB Podpora pre pamäte typu: DDR4 *Dual Channel Memory Architecture *OptiMem II *ECC Memory (ECC mode) support varies by CPU

Grafické výstupy: Integrated Graphics Processor (na základe procesora) *1x DisplayPort 1.2 *1x HDMI 2.1(4K@60HZ)

Multi GPU: *AMD 2-Way CrossFireX Technology

Zvuková karta: *ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A

Sieťová karta: *Intel® I225-V 2.5Gb Ethernet (ASUS LANGuard)

Rozširujúce sloty: *1x PCIe 4.0 x16 (x16 mode) *1x PCIe 3.0 x16 (x4 mode) *3x PCIe 3.0 x1

RAID radič: 0, 1, 10

SATA: *6x SATA 6Gb/s port(s)

M.2 : *1x M.2_1 socket 3, s M kľúčom, typ 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode) *1x M.2_2 socket 3, s kľúčom M, 2242/ 2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)

USB: * zadné USB porty ( celkom 8 ) *2x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C®) *4x USB 3.2 Gen 1 port(s)(4 x Type- A) *2x USB 2.0 port(s) * predné USB porty ( celkom 6 ) *2x USB 3.2 Gen 1 port(s) *4x USB 2.0 port(s)

Interné porty: *1x CPU Fan konektor(s) *1x CPU OPT Fan konektor(s) *3x Chassis Fan konektor(s) *1x AIO_PUMP konektor *1x AAFP konektor *2x Aura RGB Strip Header(s) *1x Addressable Gen 2 header(s) *1x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) *2x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port (s) *1x M.2 Socket 1 s M kľúčom, typ 2242/2260/2280/22110 storage devices support(SATA & PCIe 4.0 x4 mode) *1x M.2 Socket 2 s kľúčom M, typ 2242/2260/2280 /22110 storage devices support (SATA & PCIE 3.0 x 4 mode) *6x SATA 6Gb/s konektor(s) *1x Thunderbolt header(s) *1x 24-pin EATX Power connector(s) *1x 8-pin ATX 12V Power connector(s) *1x 4-pin ATX 12V Power connector(s) *1x System panel(s) *1x Thermal sensor connector(s) *1x Clear CMOS jumper(s)

Externé porty: *1x Intel® I225-V 2.5Gb Ethernet *1x DisplayPort *1x HDMI *2x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C®) * 4x USB 3.2 Gen 1 *2x USB 2.0 *1x Optical S/PDIF out *1x BIOS FlashBack™ Button(s) *5x Gold-plated audio jacks

Obsah balenia: *User's manual *4x SATA 6 Gb/s cable(s) *1x Supporting DVD *1x ROG Strix stickers *1x Cable ties pack(s) *1x Extension cable for Addressable LED *1x ROG Thank you card *1x M. 2 SSD screw package(s) *1x M.2 Rubber Package(s)

BIOS: 256 Mb Flash ROM, UEFI AMI BIOS

Stránka výrobcu: https://www.asus.com/Motherboards/ROG-STRIX-B550-F-GAMINGhttps://www.asus.com/microsite/motherboard/ASUS-motherboards-Win11-ready/ https:// www.asus.com/support/FAQ/1046215
