Chipset: B550

Rozmerový formát: ATX (30.5cm x 24.4cm) Podpora pre procesory: AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series

Pozícia na pamäti: 4 x DIMM,DDR4 Podpora pre pamäte: * AMD Ryzen 5000 a 3000 Series Desktop Procesors *DDR4 4800( OC)/4666(OC)/4600(OC)/4400(OC)/4266(OC)/4133 (OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3200/3000/2933/2800/2666/2400/2133 MHz * AMD Rýzeň 5000 a 4000 G-Series Processors *DDR4 5100( OC)/4866(OC)/4600(OC)/4466(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/ 3866(OC)/3600(OC)/3466(OC)/3200/3000/2800/2666/2400/2133 MHz, Max. veľkosť operačnej pamäte: 128 GB Podpora pre pamäte typu: ECC

Zvuková karta: ROG SupremeFX 7.1-Channel High Definition Audio CODEC S1220A

Sieťová karta: *1 x Intel I225-V 2.5Gb Ethernet *WI-FI 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) *Bluetooth v5.2

Rozširujúce sloty: *1 x PCIe 4.0 x16 SafeSlot (supports x16 mode) *1 x PCIe 3.0 x16 slot (supports x4 mode) *3 x PCIe 3.0 x1 slots

RAID radič: RAID 0, 1, 10

SATA: 6 x SATA 6Gb/s ports

M.2 : 2 x M.2 slots (Key M)

USB: * Interné: *1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports *2 x USB 2.0 headers support additional 4 USB 2.0 ports * Externý: *2 x USB 3.2 Gen 2 ports (1 x Type-A + 1 x USB Type-C) *4 x USB 3.2 Gen 1 ports (4 x Type-A) *2 x USB 2.0 ports

Interné porty: * Fan and cooling related *1 x 4-Pin AIO_Pump header *1 x 4-Pin CPU fan header *1 x 4-Pin CPU_OPT fan header *3 x 4-Pin Chassis fan headers * Power related *1 x 24 -pin main power connector *1 x 8-pin +12V power connector *1 x 4-pin +12V power connector * Storage related *2 x M.2 slots (Key M) *6 x SATA 6Gb/s ports * USB ports *1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports *2 x USB 2.0 headers support additional 4 USB 2.0 ports * Miscellaneous *1 x Addressable Gen 2 header *2 x AURA RGB headers *1 x Clear CMOS header 1 x Front panel audio header (AAFP) *1 x 20-3 pin

Externé porty: *2 x USB 3.2 Gen 2 portov (1 x Type-A + 1 x USB Type-C) *4 x USB 3.2 Gen 1 ports (4 x Type-A) *2 x USB 2.0 ports *1 x Wi -Fi Modul *1 x DisplayPort *1 x HDMI port *1 x Intel I225-V 2.5G Ethernet *1 x Optical S/PDIF out *5 x Audio jacks *1 x BIOS FlashBack button

BIOS: UEFI AMI BIOS, 256 Mb Flash ROM
