Chipset Intel Z590
CPU SUPPORT Support for 10th/11th Generation Intel Core i9/ i7/ i5/ i3 procesory a Intel Pentium processors/ Intel Celeron® procesory v balíku LGA1200
Supports Intel Turbo Boost Max 3.0 Technology

• Please refer to na www.biostar.com.tw for CPU support list.

  MEMORY Supports Dual Channel DDR4 5000+(OC)/ 4333(OC)/ 4266(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC) / 3200/ 2933/ 2800/ 2666/ 2400/ 2133
  2 x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
  Each DIMM supports non-ECC 4/ 8/ 16/ 32GB DDR4 module
  Support Intel Extreme Memory Profile (XMP) memory modules

• Please refer to www.biostar.com.tw pre Memory support list

  INTEGRATED VIDEO By CPU model
  Supports DX12
  Supports HDCP

  STORAGE -- Total supports 2 x M.2 socket a 4 x SATA III (6Gb/s) ports
  4 x SATA III Connectors (6Gb/s) : Supports AHCI, RAID 0, 1, 5, 10 & Intel Rapid Storage Technology
  1 x M.2 (M Key) Socket (M2_PCIEG4_64G_11TH_ONLY):
  Supports M.2 Type 2280 SSD module
  Supports PCIe 4.0 x 4 (64Gb/s) - NVMe/ AHCI SSD
  Support 11th Gen processor only
  1 x M.2 (M Key) Socket (M2_PCIEG3_32G_SATA_RST_1):
  Supports M.2 Type 2280 SSD module
  Supports PCIe 3.0 x4 (32Gb/s) - NVMe/AHCI SSD & SATA III (6Gb/s) SSD
  Supports Intel Rapid Storage Technology and Intel Optane Technology

• M.2 (M Key) Socket (M2_PCIEG4_64G_11TH_ONLY) support 11th Gen Rocket Lake-S CPU only.

• M.2 (M Key) Socket (M2_PCIEG3_32G_SATA_RST_1) je za motherboard.

• Pri používaní modulu SATA SSD na M.2 slot(M2_PCIEG3_32G_SATA_RST_1), SATA_5 konektor sa bude disabled.

  LAN Realtek RTL8125B
  10/ 100/ 1000/ 2500 Mb/s auto negotiation, Half / Full duplex capability

  AUDIO CODEC ALC1220
  7.1 Channels, High Definition Audio, Hi-Fi(Front)

  USB 1 x USB 3.2 (Gen2x2) Type-C port (1 on rear I/O)
  2 x USB 3.2 (Gen2) porty (2 on rear I/Os)
  5 x USB 3.2 (Gen1) ports(3 on rear I/Os a 2 via internal header)
  4 x USB 2.0 ports (2 na diaľku I/Os a 2 via internal header)

  EXPANSION SLOT 1 x PCIe 4.0 x 16 Slot (x16 mode)

• According to different CPUs budú mať rôzne rýchlosti.

• PCIe 4.0 speed only pre INTEL 11th Gen CPUs.

  REAR I/O 2 x WIFI Antenna Ports
  1 x PS/2 Keyboard/ Mouse Port
  1 x HDMI Port (HDMI2.0)
  1 x DP Port
  1 x USB 3.2 (Gen2x2) Type-C Port
  2 x USB 3.2 (Gen2) Ports
  3 x USB 3.2 (Gen1) ports
  2 x USB 2.0 ports
  1 x 2.5 GbE LAN port
  3 x Audio Jack


  INTERNAL I/O 4 x SATA III Connectors (6Gb/s)
  1 x M.2 (E Key) Socket : Supports 2230 typu Wi-Fi a Bluetooth modulu a Intel CNVi
  1 x USB 2.0 Header (each header supports 2 USB 2.0 ports)
  1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
  1 x 8-Pin Power Connector
  1 x 24-Pin Power Connector
  1 x CPU Fan Connector
  1 x CPU water cooling connector (CPU_OPT)
  1 x System Fan Connector
  1 x MOSFET Fan Connector
  1 x Front Panel Header
  1 x Front Audio Header
  1 x Internal Stereo Speaker Header
  1 x Clear CMOS Header
  1 x Thunderbolt 3 Header
  1 x LED Header (5V)
  1 x LED Header (12V)

• M.2 (E key) Wi-Fi card is not provided

  H/W MONITORING CPU / System Temperature Monitoring
  CPU / System Fan Monitoring
  Smart / Manual CPU Fan Control
  System Voltage Monitoring

  DIMENSION Mini ITX Form Factor Dimension: 17 cm x 17 cm ( W x L )

  OS SUPPORT Supports Windows 10(64bit)
  ?Biostar uistite sa, že ste pripravení alebo odstráňte podporu pre OS s alebo bez oznámenia.

  BUNDLE SOFTWARE BullGuard
  AURORA Utility

  ACCESSORIES 4 x SATA Cable
  1 x DVD Driver
  1 x Quick Guide
  1 x WiFi accessories
  1 x Smart Connector

  FEATURES VIVID LED DJ
  M.2 Cooling Protection
  Tweak Tech
  BIOS-Flasher
  AI FAN
  LED ROCK ZONE
  RGB Memory Sync
  BIOSTAR Flash
  BIOS EZ Mode/Advanced Mode
  Intel Optane technology

  Caution!! Špecifikácia a obrázky sú predmetom zmeny bez oznámenia!
