Chipset: AMD B650

Rozmerový formát: Micro ATX Form Factor; (24.4cm x 24.4cm) Podpora pre procesory: AMD Ryzen 7000 Series Processors Pätica procesora: AM5

Pozícia na pamäti: 4 x DDR5 DIMM, Dual channel memory architecture Podpora pre pamäte: DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules Max. veľkosť operačnej pamäte: 128 GB (32 GB single DIMM capacity) Podpora pre pamäte typu: non-ECC, XMP

Grafické výstupy: (na základe procesora) *2 x DisplayPorts 1.4, maximálne rozlíšenie 3840x2160@144 Hz *1 x HDMI 2.1 port, maximálne rozlíšenie 4096x2160@60 Hz

Zvuková karta: Realtek Audio CODEC 2/4/5.1/7.1-channel

Sieťová karta: *Realtek 2.5GbE LAN čip (2.5Gbps/1Gbps/100Mbps) *AMD Wi-Fi 6E RZ616 a, b, g, n, ac, ax *Bluetooth 5.2

Rozširujúce sloty: *1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) *1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1)

RAID radič: RAID 0, RAID 1, and RAID 10

SATA: 4 x SATA 6Gb/s konektory M.2 : 2 x M.2 Socket 3 konektory

USB: * Interný: *1 USB Type-C header, s USB 3.2 Gen 2 support *1 x USB 3.2 Gen 1 header *2 x USB 2.0/1.1 headers * Externý: *1 x USB 3.2 Gen 2 Type-A port (red) *2 x USB 3.2 Gen 1 ports *1 x USB Type-C port, with USB 3.2 Gen 2 support *4 x USB 2.0/1.1 ports

Interné porty: 1 x 24-pin ATX main power connector 2 x M.2 Socket 3 konektory *4 x SATA 6Gb/s konektory *1 x front panel header *1 x front panel audio header *1 x USB Type-C header, s USB 3.2 Gen 2 support *1 x USB 3.2 Gen 1 header *2 x USB 2.0/1.1 headers *1 x Trusted Platform Module header (For GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) *1 x serial port header *1 x reset button *1 x reset jumper *1 x Clear CMOS jumper

Externé porty: *4 x USB 2.0/1.1 ports *1 x PS/2 keyboard/mouse port *2 x SMA antenna connectors (2T2R) *2 x DisplayPorts *1 x HDMI port *1 x USB 3.2 Gen 2 Type-A port (red) * 1 x USB Type-C port, s USB 3.2 Gen 2 support *1 x Q-Flash Plus tlačidlo *1 x RJ-45 port *2 x USB 3.2 Gen 1 ports *3 x audio jacks

BIOS: AMI UEFI BIOS, 1 x 256 Mbit flash

Stránka výrobcu: http://www.gigabyte.com/Motherboard/B650M-GAMING-X-AX-rev-1x#kf
