NetXtreme Quad Port Ethernet adaptér je ideálny spôsob, ako implementovať virtuálne riešenie pomocou vášho existujúceho Gigabit Ethernet. S štyrmi copper-based gigabitových portov na single PCI Express 2.0 x4 interface, adaptér prevádza density a kapacity, ktoré potrebujú na podporu veľkých čísel virtualizovaných systémov na jednom serveri.

Adaptéri majú following features:
•One, dva, alebo štyri 10/100/1000 copper ports s RJ45 pre Cat 5e/6 káblové
•Full line-rate performance across all ports
•Low-profile form factor - podporovaný systémom x a iDataPlex serverov
•PCI Express 2.0 host interface (39Y6066 aj s PCI Express 1.1)
•Jumbo Frames support (9600 bytes frames)
• IEEE 802.1q VLAN support - provides enhanced network management and efficiency
•I/O virtualizácia (IOV) support for VMWare NetQueue a Microsoft VMQ - improves network performance in virtualized environments
•IEEE 802.3x flow control support
•Receive and transmit side scaling
•TCP, IP, a UDP checksum offload
•Message Signaled Interrupts (MSI) a MSI-X support - Maximizes server procesnej performance by reducing CPU overhead and lowering interrupt latency
•On-chip temperature monitor (NetXteme I only)
•IEEE 802.3az Energy Efficient Ethernet (EEE) compliant - Znížený adaptér power consumption by up to 42% cez inteligentné adaptívne power management, adjusting power based on data traffic load. (NetXtreme I only)
•IEEE 802.3z (Clause 30) - Statistics pre SNMP MIB II, Ethernet ako MIB, a Ethernet MIB (NetXtreme I only)
•IEEE 1588 Precision Time Control and 802.1AS time synchronization support - Provides greater accuracy of data packet delivery within the network (NetXtreme I only)
•Management using Broadcom Advanced Control Suite (BACS), Windows Management Instrumentation (WMI) a Broadcom Management API (BMAPI)


Redbooks - https://lenovopress.com/tips0758-broadcom-netxtreme-gigabit-ethernet-adapters
