Chipset: AMD B550

Rozmerový formát: Formát ATX (305 mm x 244 mm)
Podpora pre procesory: 3rd Gen AMD Ryzen processors, a future AMD Ryzen processors with BIOS update
Pätica procesora: AM4

Pozícia na pamäti: 4x DDR4
Podpora pre pamäte:
•Supports DDR4 1866/2133/2400/2667/2800/2933/3000/3066/3200 MHz by JEDEC
•Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE

Max.veľkosť operačnej pamäte: 128 GB
Podpora pre pamäte typu: DDR4
•Dual channel memory architecture
•Supports non-ECC UDIMM memory
•Supports ECC UDIMM memory (non-ECC mode)
•Supports un-buffered memory

Grafická karta: na základe procesora
•1x HDMI port, supports a maximum resolution of 4096x2160 @24Hz
•1x DisplayPort, supports a maximum resolution of 4096x2160 @60Hz

Multi GPU:
•Supports 2-Way AMD CrossFire™ Technology

Zvuková karta:
• Realtek® ALC892 Codec

Sieťová karta:
•1x Realtek® 8111H Gigabit LAN controller

RAID radič:
•Supports RAID 0, RAID 1 a RAID 10 pre SATA storage devices
•Supports RAID 0 a RAID 1 pre M.2 NVMe storage devices

Rozširujúce sloty:
•1x PCIe 4.0/3.0 x16 slot (PCI_E1)
•1x PCIe 3.0 x16 slot (PCI_E3), supports x4 speed
•2x PCIe 3.0 x1 slots

SATA:
•6x SATA 6Gb/s ports

M.2 :
•2x M.2 slots (Key M)

USB:
•zadné USB porty (celkom 8)
•4x USB 2.0 ports
•1x USB 3.2 Gen 2 10 Gbps Type-C port
•1x USB 3.2 Gen 2 10Gbps port
•2x USB 3.2 Gen 1 5Gbps Type-A ports
•predné USB porty ( celkom 7 )
•1x USB 3.2 Gen 1 5Gbps Type-C port
•2x USB 3.2 Gen 1 5Gbps ports
•4x USB 2.0 ports

Interné porty:
•1x 24-pin ATX main power connector
•1x 8-pin ATX 12V power connector
•6x SATA 6Gb/s konektory
•2x M.2 slots (M-Key)
•1x USB 3.2 Gen 1 5Gbps Type-C port
•1x USB 3.2 Gen 1 5Gbps konektor (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
•2x USB 2.0 konektory (supports additional 4 USB 2.0 ports)
•1x 4-pin CPU fan connector
•1x 4-pin water-pump fan connector
•6x 4-pin system fan connectors
•1x Front panel audio connector
•2x System panel connectors
•1x Chassis Intrusion connector
•1x 4-pin RGB LED connector
•2x 3-pin RAINBOW LED connectors
•1x TPM module connector
•1x Clear CMOS jumper

Externé porty:
•PS/2 Keyboard / Mouse
•DisplayPort
•1x LAN
•HD Audio Connectors
•Flash BIOS Button
•HDMI
•4x USB 2.0
•2x USB 3.2 Gen 1 5Gbps Type-A
• 1x USB 3.2 Gen 2 10 Gbps Type-A
• 1x USB 3.2 Gen 2 10 Gbps Type-C
