Podpora stolných procesorov AMD Ryzen™ radu 7000
Podpora pamätí DDR5, až 6400+(OC) MHz
Prémiové tepelné riešenie: Rozšírená konštrukcia chladiča a M.2 Shield Frozr sú určené pre vysoko výkonný systém a nepretržitú prácu.
Riešenie 2,5 G LAN a Intel Wi-Fi 6E: Modernizované sieťové riešenie pre profesionálne a multimediálne použitie. Poskytuje bezpečné, stabilné a rýchle sieťové pripojenie.
Lightning M.2 : Beh na PCIe Gen 4 maximalizuje výkon SSD diskov založených na NVMe
Lightning USB 20G: Vstavaný port USB 3.2 Gen 2x2, ponúka prenosovú rýchlosť 20 Gb/s, 4x rýchlejšiu ako USB 3.2 Gen 1.
AUDIO BOOST 5: Doprajte svojim ušiam štúdiovú kvalitu zvuku pre najúžasnejší herný zážitok.

CHIPSET AMD B650
CPU Supports AMD Ryzen™ 8000/7000 Series Desktop Processors
Socket AM5
MEMORY 4x DDR5, Maximum Memory Capacity 192GB
Memory Support DDR5 7600+(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800 (OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 7600+ MHz
• 1DPC 2R Max speed up to 6400+ MHz
• 2DPC 1R Max speed up to 6400+ MHz
• 2DPC 2R Max speed up to 5400+ MHz

ONBOARD GRAPHICS 1x HDMI™
Support HDMITM 2.1 s HDR, maximum resolution of 4K 60Hz*
1x DisplayPort
Support DP 1.4, maximum resolution of 8K 60Hz*
Available only on processors featuring integrated graphics. Graphics specifications majú vary depending on the CPU inštalované.
SLOT 2x PCI-E x16 slot (Qty)
Support x16/ x4
1x PCI-E x1 slot (Qty)
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 4.0 supports up to x2 (From Chipset)
PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)
STORAGE 3x M.2 (Qty)
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
6x SATA 6G (Qty)
RAID Supports RAID 0, RAID 1, a RAID 10 pre SATA storage devices
Supports RAID 0 a RAID 1 pre M.2 NVMe storage devices

• SATA_A1_A2 do not support RAID function.
  USB 2x USB 2.0 (Rear)
  4x USB 2.0 (Front)
  4x USB 3.2 Gen1 Type A (Rear)
  2x USB 3.2 Gen1 Type A (Front)
  3x USB 3.2 Gen2 Type A (Rear)
  1x USB 3.2 Gen2 Type C (Front)
  1x USB 3.2 Gen2x2 Type C (Rear)
  LAN Realtek® RTL8125B 2.5Gbps LAN
  WIRELESS LAN & BLUETOOTH AMD Wi-Fi 6E
  The Wireless module je preinštalovaný v M.2 (Key-E) slot
  Supports MU-MIMO TX/RX
  Supports 20MHz, 40MHz, 80MHz, 160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands
  Supports 802.11 a/ b/ g/ n/ ac/ ax

  Supports Bluetooth® 5.3**


• Wi-Fi 6E 6GHz má depend on every country's regulations and will be ready in Windows 11.
  ** Bluetooth 5.3 bude ready in Windows 10 budova 21H1 a Windows 11.
  AUDIO Realtek® ALC4080 Codec
  7.1-Channel High Performance Audio
  Supports S/PDIF output
  Supports up to 32-Bit/384 kHz playback on front panel
  INTERNAL IO 1x Power Connector(ATX_PWR)
  2x Power Connector(CPU_PWR)
  1x CPU Fan
  1x Pump Fan
  6x System Fan
  2x Front Panel (JFP)
  1x Chassis Intrusion (JCI)
  1x Front Audio (JAUD)
  1x Tuning Controller connector (JDASH)
  2x Addressable V2 RGB LED konektor (JARGB_V2)
  2x RGB LED connector (JRGB)
  1x TPM pin header (Support TPM 2.0)
  4x USB 2.0 ports
  2x USB 3.2 Gen1 Type A ports
  1x USB 3.2 Gen2 Type C ports
  LED FEATURE 4x EZ Debug LED
  BACK PANEL PORTS
  DisplayPort 1.4
  2.5G LAN Port
  USB 2.0 Port
  USB 3.2 Gen 1 5Gbps Type-A
  Wi-Fi / Bluetooth Antenna
  HD Audio Connectors
  Flash BIOS Button
  HDMI™ 2.1 Port
  USB 3.2 Gen 2 10Gbps Type-A
  USB 3.2 Gen 2x2 20Gbps Type-C
  Optical S/PDIF OUT

  OPERATING SYSTEM Support for Windows® 11 64-bit, Windows® 10 64-bit
  PCB INFO ATX
  243.84mmx304.8mm
