Supports 12th/13th Gen Intel® Core™, Pentium® Gold and Celeron® procesory pre LGA 1700 socket
Supports DDR5 Memory, až 7000+(OC) MHz
Enhanced Power Design: 12+1+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost
Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 4x4 M.2 , USB 3.2 Gen 2x2
Premium Thermal Solution: Extended Heatsink Design a M.2 Shield Frozr are built for high performance system and non-stop works
AUDIO BOOST: Reward your ears with štúdio triedy zvukovej kvality pre most immersive gaming experience
High Quality PCB: 6-layer PCB vytvorený pre 2oz thickened copper and server

CHIPSET INTEL B760
CPU SUPPORT Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors
LGA1700
MEMORY 4x DDR5, Maximum Memory Capacity 192GB
Memory Support 7000+(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200 JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 7000+ MHz
• 1DPC 2R Max speed up to 6600+ MHz
• 2DPC 1R Max speed up to 6400+ MHz
• 2DPC 2R Max speed up to 5600+ MHz

Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile
ONBOARD GRAPHICS 1x HDMI™
Support HDMITM 2.1 s HDR, maximum resolution of 4K 60Hz*
1x DisplayPort
Support DP 1.4, maximum resolution of 8K 60Hz*
Available only on processors featuring integrated graphics. Graphics specifications majú vary depending on the CPU inštalované.
EXPANSION SLOT 2x PCI-E x16 slot
Supports x16/x4
1x PCI-E x1 slot
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x4 (From Chipset)
PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset)
STORAGE 3x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
4x SATA 6G
RAID Supports RAID 0, RAID 1, RAID 5 a RAID 10 pre SATA storage devices
USB 4x USB 2.0 (Rear)
4x USB 2.0 (Front)
2x USB 3.2 Gen1 Type A (Front)
4x USB 3.2 Gen2 Type A (Rear)
1x USB 3.2 Gen2 Type C (Front)
1x USB 3.2 Gen2x2 Type C (Rear)
LAN Realtek® 2.5Gbps LAN
WIRELESS / BLUETOOTH Intel® Wi-Fi 6E
The Wireless module je preinštalovaný v M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax

Supports Bluetooth® 5.3, FIPS, FISMA

• Wi-Fi 6E 6GHz má depend on every country's regulations and will be ready in Windows 11.
  ** Bluetooth 5.3 bude ready in Windows 10 budova 21H1 a Windows 11.
  AUDIO Realtek® ALC897 Codec
  7.1-Channel USB High Performance Audio
  Supports S/PDIF output
  INTERNAL I/O 1x Power Connector(ATX_PWR)
  2x Power Connector(CPU_PWR)
  1x CPU Fan
  1x Pump Fan
  5x System Fan
  2x Front Panel (JFP)
  1x Chassis Intrusion (JCI)
  1x Front Audio (JAUD)
  1x TBT konektor (JTBT, supports RTD3)
  1x Tuning Controller connector (JDASH)
  2x Addressable V2 RGB LED konektor (JARGB_V2)
  2x RGB LED connector (JRGB)
  1x TPM pin header (Support TPM 2.0)
  4x USB 2.0 ports
  2x USB 3.2 Gen1 Type A ports
  1x USB 3.2 Gen2 Type C ports
  LED FEATURE 4x EZ Debug LED
  BACK PANEL PORTS
  USB 2.0
  DisplayPort 1.4
  USB 3.2 Gen 2 10Gbps Type-A
  2.5G LAN Port
  Wi-Fi / Bluetooth Antenna
  HD Audio Connectors
  HDMI™ 2.1 Port
  USB 3.2 Gen 2x2 20Gbps Type-C
  Optical S/PDIF OUT

  OPERATING SYSTEM Support for Windows® 11 64-bit, Windows® 10 64-bit
  PCB DIMENSION ATX
  243.84mmx304.8mm
